AeroSorber AB525 Model · in Thermal RF Absorber
Lianxin-Sorber AB525, an interface material which is both thermally conductive and RF radiation absorptive; it is a…
- Thermal conductivity
- 4.5 W/m·K
| PROPERTIES | UNIT | TEST METHOD | AB525 |
|---|---|---|---|
| Appearance | - | Visual | Grey |
| Resin system | - | - | Silica Gel |
| Filler | - | - | Carbonyl Iron Powder |
| Hardness | Shore OO | ASTM D2240 | 60 |
| Density | g/cm³ | ASTM D792 | 3.9 |
| Dielectric Constant ε'(77GHz) | - | SJ20512-1995 | 10.06 |
| Dielectric Constant ε"(77GHz) | - | SJ20512-1995 | 1.58 |
| Insertion loss 1mm (77GHz) | dB | LIANXIN-70/90 (Transmission method) | -7.03 |
| Operating Temperature | ℃ | ASTM D1329 | -45~+200 |
| Volume Resistivity | Ohm-cm | ASTM D257 | ≥10 9 |
| Breakdown Voltage | KV | ASTM D149 | 4.55 |
| Flammability Rating | - | U.L. 94 | V-0 |
| Thermal Conductivity | W/m·K | ASTM D5470 | 4.5 |
| Thermal resistance VS pressure | Pressure PSI | - | 5 |
| Thermal resistance VS pressure Thermal Resistance ℃·in²/w | 0.299 |
About the model
Lianxin-Sorber AB525, an interface material which is both thermally conductive and RF radiation absorptive; it is a compound of ceramic powder, magnetic filler and corresponding additives. The product can achieve thermal conduction and microwave absorption at low compression force, and it has good insulation properties and environmental stability.
Lianxin-Sorber AB 525 is a blended absorber/ thermal management material which can be used to bridge the gap/distance between a noisy & hot component and itsheatsink. Its thermal conductivity can reach 4.5W and is suitable for broad band & high RF range.
