NOMAX T410 Model · in LIANXIN-INSU™ Insulating Material
Dupont FOMAX/NOMAX is a calendered insulation liner. Nomex® 410 is a family of insulation papers that offer high…
- Thickness
- 0.13 – 0.76
| Characteristic | NOMEX ® 410 | Test method | col1 | col2 | col3 | col4 | col5 | col6 | col7 | col8 | col9 | col10 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal thickness (mm) | 0.05 | 0.08 | 0.13 | 0.18 | 0.25 | 0.30 | 0.38 | 0.51 | 0.61 | 0.65 | 0.73 | 0.76 |
| Nominal thickness (mm) Dielectric loss factor (3) 60Hz (x10 3 ) | 6 | 6 | 6 | 7 | 7 | 7 | 7 | N/A | 7 | 7 |
About the model
Dupont FOMAX/NOMAX is a calendered insulation liner. Nomex® 410 is a family of insulation papers that offer high inherent dielectric strength, mechanical toughness, flexibilityand resilience. Nomex® 410, the original form of Nomex® paper, is widely used in a majority of electrical equipment applications. Available in 11 thicknesses ranging from 0.05 mm to 0.76 mm (2 mil to 30 mil), Nomex® 410 is used in almost every known electrical sheet insulation application.
(1)ASTM D-149 uses 50mm (2-inch) electrode and can rise fast; it conforms to 9.1 of IEC 243-1, only that the electrode is set as 50 mm (2 inches).
⑵ASTM D-3426
⑶ASTM D-150
